Magnetresonance Imaging (MRI)

ClinScan 70/30 7 Tesla MRI System

Specifications ClinScan 70/30, Bruker

  • field intensity: 7 Tesla
  • in-plain resolution up to 50µm, minimal slice thickness approx. 100µm (dependent on sequence)
  • proton- and sodium imaging supported
  • surface coils and whole-body coils available for mice and rats

Example images

Figure 1: bonemetastasis near knee

Figure 2: follow-up of muscle-inflammation

Figure 3: slice through the heart after ECG- and respiration triggering
